Maag system can hold many tough process like high temperature, low inlet, high viscosity or applications involving corrosion. Thanks to the extensive range of components and materials of construction to choose from, maag gear pumps can be configured to suit customers' specific requirements and are therefore far superior to standard pumps in terms of performance and reliability.
Viscosity:0.3 to 4,000,000 mPas
Temperature Range：-30 to 150°C
Suction Pressure:Vacuum up to 65 bar
Discharge Pressure:Vacuum up to 120 bar
Flow Rate 2): 0.1 to 1,750 l/min
Housing Material: Pressure-Resistant Cast Iron
Viscosity: 0.3 to 4,000,000 mPas
Temperature: -30 to 320°C
Suction Pressure:Vacuum up to 65 bar
Discharge Pressure:Vacuum up to 350 bar
Flow Rate 2): 0.5 to 1,750 l/min
Housing Material:Pressure-Resistant Cast Steel
Viscosity:0.3 to 4,000,000 mPas
Temperature Range： -30 to 320°C
Suction Pressure: Vacuum up to 65 bar
Discharge Pressure:Vacuum up to 200 bar
Flow Rate2):0.1 to 2,400 l/min
Housing Material:Stainless Steel\ Hastelloy
Viscosity: 0.3 to 4,000,000 mPas
Temperature Range： -30 to 320°C
Suction Pressure:Vacuum up to 16 bar
Discharge Pressure：Vacuum up to 200 bar
Flow Rate 2): 2.5 to 265 l/min
Housing Material: Stainless Steel
Viscosity 2): To 60 Pas
Temperature Range：To 350°C
Suction Pressure: Pumped media flow under vacuum or at an admission pressure to 10 bar
Discharge Pressure:To 120 bar
Housing Material: Stainless Steel
2) Higher viscosities upon request
