Sundyne HMD Kontro is the home of the sealless pump. As the first to develop the magnetic drive for pumping applications, over sixty years ago, we have honed and perfected this expertise to provide a comprehensive range of pumps that all offer the significant benefits of zero leakage.
Flows up to：3,000 GPM (690 m³/hr)
Heads to：790 ft (240m)
Temperature Range：-40 to 660°F (-40 to 350°C)
Available Flanges：150#/300# RF
Solids Range：Maximum of 5% w/w less than 150 microns
Housing Material：S-5, A-8, Duplex Stainless steel, Alloy20 and Alloy C276
Flows：up to 1,035 GPM (235 m³/hr)
Heads：to 295 ft (90m)
Temperature Range：-40 to 400°F (-40 to 205°C)
Available Flanges ：150#/300# RF
Solids Range：Maximum of 5% w/w less than 150 microns
Housing Material：S-5, A-8, Duplex Stainless steel, Alloy20 and Alloy C276
Flows：up to 1,420 GPM (320 m³/hr)
Heads：to 485 ft (150m)
Temperature Range：-40 to 500°F (-40 to 205°C) * *
Available Flanges ：150#/300# RF
Solids Range: Maximum of 5% w/w less than 150 microns
** -100°C on Request
Flows：up to 1,163 GPM (264 m³/hr)
Heads：to 344 ft (105m)
Temperature Range：-112 to 850°F (-80 to 450°C)
Available Flanges：150#/300# RF
Solids Range：Maximum of 1.5% w/w less than 100 microns
Housing Material：Carbon Steel, 316 St St
Flows：up to 375 GPM (85 m³/hr)
Heads：to 970 ft (295m)
Temperature Range：-40 to 500°F (-40 to 260°C)
Available Flanges150#/300# RF
Solids Range：Maximum of 5% w/w less than 100 microns
Housing Material：S-5, A-8, D-1, D-2
Flows： up to 200 GPM (45 m³/hr)
Heads：to 165 ft (50m)
Temperature Range：-40 to 248°F (-40 to 120°C)
Available Flanges：150#/300# RF
Solids Range：Maximum of 5% w/w less than 150 microns
Housing Material：316 St St, Alloy 20, Alloy C
